New PCB's
Hi Gain Bass Treble Board with Input Selector
Hi Gain Bass Treble Board with Input Selector
Hi Gain Bass Treble Board with Input Selector
- High performance Super Bass Treble board
- Up to 17dB Bass / Treble Boost & Cut.
- 26 dB Signal Gain.
- Compact Size , Easy to make
- Working Voltage - ±12 to ±15 Volt DC
600 Watt MOSFET Amplifier using IRFP240 9240
Hi Gain Bass Treble Board with Input Selector
Hi Gain Bass Treble Board with Input Selector
- For DJ's, and Public Address systems
- High Power & Redundancy.
- Output Short Circuit Protection.
- Working Voltage - ±24 to ±65 Volt DC
- Transformer Recommended - 40 0 40 VAC 5 - 10 Ampere
Multi Use Power Supply Board
Hi Gain Bass Treble Board with Input Selector
Multi Use Power Supply Board
- Regulated - +5v, +15v, -15v supply
- Unregulated supply - 10 ampere Max Bridge Rectifier.
- One or Two Transformers Can be Connected.
- Versatile - use in 2.1 Home Theater Systems, Subwoofer Amps or Hobby projects.
- Max Capacitor Diameter - 18 mm
High power Transistor amplifier boards
400 watt Hi Fi Mono Amplifier
100 Watt Mosfet Amplifier board
100 Watt Mosfet Amplifier board
- Real HiFi Amplifier
- Ultra low Distortion & Noise
- Best for Home audio & Studio Amplifiers.
- Working Voltage - ±18 to ±45 Volt DC
- Transformer Recommended - 30 0 30 VAC 5 - 8 Ampere
100 Watt Mosfet Amplifier board
100 Watt Mosfet Amplifier board
100 Watt Mosfet Amplifier board
- 100w Mosfet Amplifier using IRFP240 IRFP9240 power mosfets
- Simple Board with Super Performance.
- Vintage Amplifier Board.
- Working Voltage - ±18 to ±45 Volts Dual DC Supply.
- Transformer Recommended - 24 0 24 VAC 5 Ampere
100 Watt Mono Amplifier board
100 Watt Mosfet Amplifier board
100 + 100 watt Stereo amplifier with Power Supply
- Just Basic Knowledge of Electronics required.
- Simple Circuit with excellent Performance.
- All round general purpose amplifier
- Working Voltage - ±18 to ±35 Volts Dual DC Supply.
- Transformer Recommended - 24 0 24 VAC 5 Ampere
100 + 100 watt Stereo amplifier with Power Supply
100 + 100 watt Stereo amplifier with Power Supply
100 + 100 watt Stereo amplifier with Power Supply
- 100 + 100 Watt RMS stereo Amplifier
- On board power supply rectifier with DC out
- Heavy Duty rectifier and Big Filter Capacitors
- Easy to make 2.1 home theater Amplifier
- 24 0 24 VAC 5 - 8 Amp Transformer recommended
200 watt Hi Fi Mono Amplifier
100 + 100 watt Stereo amplifier with Power Supply
200 watt Hi Fi Mono Amplifier
- Real Hi Fi Amplifier, Requires expertise.
- Ultra Low Distortion & Noise
- Best for Home Audio.
- Working Voltage - ±18 to ±45 Volt DC
- Transformer Recommended - 30 0 30 VAC 3 - 5 Ampere
best Audio Power IC amplifier boards
TDA7294 100 Watt Mono Amplifier Board
TDA2030 TDA2050 20 + 20 Watt Stereo Amplifier Board
TDA2030 TDA2050 20 + 20 Watt Stereo Amplifier Board
- Low cost high power amplifier board
- Compact size = fit in any box
- Best for Subwoofers, Guitar amplifier & Home Audio systems
- Working Voltage - ±18 to ±35 Volt DC
- Transformer Recommended - 24 0 24 VAC 5 Ampere
TDA2030 TDA2050 20 + 20 Watt Stereo Amplifier Board
TDA2030 TDA2050 20 + 20 Watt Stereo Amplifier Board
TDA2030 TDA2050 20 + 20 Watt Stereo Amplifier Board
- A learning tool for Beginners
- Easily available components
- Best for Desktop / Laptop stereo speakers
- Working Voltage - ±12 to ±22 Volt DC
- Transformer Recommended - 15 0 15 VAC 3 ampere
TDA7265 2.1 Home theater / Car Amplifier Board
TDA2030 TDA2050 20 + 20 Watt Stereo Amplifier Board
TDA7265 2.1 Home theater / Car Amplifier Board
- 2.1 Channel amplifier with low pass filter using NE5532
- 30 + 30 watt stereo + 60 watt subwoofer
- Best for making Home Theater systems, Car Subwoofer Amplifier
- Working Voltage - 12 to 36 Volt DC Single Supply
- Battery operation - can be used in Vehicles like Cars, buses, trucks & tractors
pre amp / Bass treble / subwoofer boards
Hi Gain Bass Treble Board with Input Selector
NE5532 4558 TL072 Subwoofer Low pass Filter Board
NE5532 4558 TL072 Subwoofer Low pass Filter Board
- High performance Super Bass Treble board
- Up to 17dB Bass / Treble Boost & Cut.
- Up to 26 dB Signal Gain.
- Compact Size , Easy to make
- Working Voltage - ±12 to ±15 Volt DC
NE5532 4558 TL072 Subwoofer Low pass Filter Board
NE5532 4558 TL072 Subwoofer Low pass Filter Board
NE5532 4558 TL072 Subwoofer Low pass Filter Board
- Up to 24dB Bass Boost.
- Frequency Adjust for subwoofer
- High gain output for ic, transistor or mosfet amplifiers
- on board Phase Switch
- Ultra compact design
- ±12 0 12 or ±15 0 15 volt DC supply required
Hifi Stereo Pre amp & Bass Treble Gain Board
NE5532 4558 TL072 Subwoofer Low pass Filter Board
Hifi Stereo Pre amp & Bass Treble Gain Board
- Stereo Pre amp using NE5532 ic to amplify input signal.
- Hi fidelity stereo Bass treble
- Separate gain control for each channel
- on board regulated power supply
- Transformer recommended - 15 0 15 VAC 1A
power supplies & other boards
10 Ampere Power Supply Rectifier Board for Audio amplifiers
10 Ampere Power Supply Rectifier Board for Audio amplifiers
10 Ampere Power Supply Rectifier Board for Audio amplifiers
- Designed for High Power Audio amplifier applications
- Dual Rail power supply with fuse protection & LED indicators
- Easy to Assemble and operate
- Screw Terminal Connectors - 4.1 & 2.1 amplifier support
- Transformer - any Centre tapped transformer up to 10 Amps
6v / 12v LED Emergency Light Board using LM317
10 Ampere Power Supply Rectifier Board for Audio amplifiers
10 Ampere Power Supply Rectifier Board for Audio amplifiers
- Simple and Reliable auto cut emergency light board
- 6v and 12v Battery support
- Easy to assemble and operate
- Automatic charging- battery over charge protection
- Transformer recommended - 0 -12v / 0-15v 1 ampere
Speaker Protection Board With On Delay
35 Ampere Audio amplifier power supply board
35 Ampere Audio amplifier power supply board
- Stereo Speaker protection board
- Turn on delay 2 - 5 Seconds ( Configurable )
- 10 ampere max current up to 600 watt Amplifier support.
- ±2 volt DC detection.
- works upto 30 volts AC supply
35 Ampere Audio amplifier power supply board
35 Ampere Audio amplifier power supply board
35 Ampere Audio amplifier power supply board
- 35 Ampere Max output current.
- Dual Rail power supply with fuse protection & LED indicators
- Capable of delivering instantaneous peak currents to amplifiers.
- Designed for High power audio amplifiers.
- Transformer - any Centre tapped transformer up to 20 Amps
upcoming pcb and kits
150 watt Amplifier using 2SC5200 / 2N3055 / 2N3773 NPN Transistors
- Quasi Complimentary version of Macaque 200w Amplifier
- Ultra Low Distortion & Noise
- Best for Home Audio.
- Working Voltage - ±18 to ±35 Volt DC
- Transformer Recommended - 24 0 24 VAC 5 Ampere with proper rectifier and filters.
