LM358 dual operational amplifier IC consisting of two independent high-gain, internally compensated op-amps in a single package. It is designed for low power consumption and supports both single and dual supply operation, making it suitable for battery-powered and general-purpose analog applications. The input common-mode range includes ground, allowing direct interfacing with low-level signals.
Configuration:
Dual operational amplifier (2 op-amps in one IC)
Through-hole package (DIP-8)
Suitable for single and dual supply operation
Electrical Characteristics:
Single supply voltage: 3 V to 32 V
Dual supply voltage: ±1.5 V to ±16 V
Low power consumption operation
Input common-mode range includes ground
Input offset voltage: ~2 mV typical
Input bias current: ~45 nA typical
Output current capability: up to ~20 mA source / ~30 mA sink
Package:
DIP-8 through-hole package
Construction:
Internally frequency compensated
True differential input stage
Short circuit protected outputs
Configuration Notes:
No external frequency compensation required
Suitable for single supply circuits without biasing
Stable operation across wide voltage range
Intended Use:
Signal conditioning circuits
Sensor amplifiers
Audio pre-amplifiers
Comparators and filters
General-purpose analog applications
